 subframe
Author Message
Street Outlaw

Joined: Sun Aug 19, 2007 10:32 am
Posts: 296
Location: Lakestevens, WA
Post subframe
I have a set of full length subframe conectors w/seat braces that I need to install, and was wondering what is the best way to go about it, other than takeing it to a shop cuz I dont have the extra cash. I have all the tools to do it (welder, grinder, ect) so thats not an issue.

_________________
I wanna go fast!
1989 Notch-DSS 331, Comp cams XE264HR, BBK cai, 8.8 swap w/
3.73s, Detroit tru track w/31 spline axles, Astro T-5
1986 GT T-top-No engine or tranny...
1987 Bronco 302-stock
ImageMatt


Sun Jul 11, 2010 3:24 pm
Profile
Founding Member/Supporter/Contributor
User avatar

Joined: Mon May 29, 2006 1:12 am
Posts: 5343
Location: DALLAS
Post Re: subframe
if you don't have a drive on lift, you'll need to get the car up on something so that the weight will be distributed on all four tires the same way it would be on flat ground. the subframe connectors i used were bolt in, so i bolted them in first and then welded them in. they will probably require some finessing to get them to line up correctly, but try not to weld them in pre-stressed. a jack will help hold them into position while you initially tack weld them.



edit: probably obvious but, make sure you have a full tank of gas! you don't wanna blow yourself up :thumbup:

_________________
Jon - 89 GT t5 3.73


Sun Jul 11, 2010 3:49 pm
Profile
Street Outlaw

Joined: Sun Aug 19, 2007 10:32 am
Posts: 296
Location: Lakestevens, WA
Post Re: subframe
I need to fill the tank anyway, but the only thing I have to het the car off the ground is jackstands, so getting the weight on the front tires might be a little tricky.

_________________
I wanna go fast!
1989 Notch-DSS 331, Comp cams XE264HR, BBK cai, 8.8 swap w/
3.73s, Detroit tru track w/31 spline axles, Astro T-5
1986 GT T-top-No engine or tranny...
1987 Bronco 302-stock
ImageMatt


Sun Jul 11, 2010 4:39 pm
Profile
Founding Member/Supporter/Contributor
User avatar

Joined: Mon May 29, 2006 1:12 am
Posts: 5343
Location: DALLAS
Post Re: subframe
Moded331 wrote:
I need to fill the tank anyway, but the only thing I have to het the car off the ground is jackstands, so getting the weight on the front tires might be a little tricky.
jack it up and set it down on some bricks or something. else, i would just wait until you have some way to do it. i've heard of some cars coming out really tweaked after subs were installed without weight on the tires. really, the suspension just needs to be loaded. in the back you could use jack stands under the axle, and in the front you could put something under the tires. just make sure the car is jacked up equal amounts on all four corners when you start welding.

_________________
Jon - 89 GT t5 3.73


Sun Jul 11, 2010 6:38 pm
Profile
Street Outlaw

Joined: Sun Aug 19, 2007 10:32 am
Posts: 296
Location: Lakestevens, WA
Post Re: subframe
Im probably going to get some of thoes stands that you drive up on. Now that you mentioned it, Im sure Ive got enough bricks and such sitting around that would work.

_________________
I wanna go fast!
1989 Notch-DSS 331, Comp cams XE264HR, BBK cai, 8.8 swap w/
3.73s, Detroit tru track w/31 spline axles, Astro T-5
1986 GT T-top-No engine or tranny...
1987 Bronco 302-stock
ImageMatt


Sun Jul 11, 2010 7:25 pm
Profile
